25A, 50A, or 100A Low Cost Three Phase Current Sensor
9091  Description
ProductModel 9089 is a low cost, three phase current switch with maximum currents of 25A, 50A, or 100 A. This three phase current sensor easily connects to PLCs. The current trip point is continuously adjustable.
Specifications
Operating Voltage
Min Max Type
3 36 VDC
Maximum Output Current 100mA
Sensing Range
Min Max Units
0.5 100 Amps
Number of Phases 3
Maximum Wire Size
3"
8
Trip Point Adjustable
Features Connects to PLC

Sensing Range (Amps)
  Model Phases Min Max
  9091 C1 3 0.5 25
  9091 C2 3 0.5 50
  9091 C3 3 0.5 100

Pricing
Quantity Price USD
1 $ 25.00
5 $ 22.00
10 $ 21.00
50 $ 18.00
100 $ 17.00
Pricing on website may not be current.
Please call for current prices.
S&H and $25 Minimum Order Apply
Downloads


Pricing on website may not be current. Please call for Pricing
