 Model 9267 is a programmable interval timer with a weekly
clock designed to operate 5 to 24 VDC. The single solid-state NPN output can switch DC
loads up to 100A. The 9267 Timer can store up to 30 intervals. Interval sequences can be programmed to start on power, daily, or weekly. The intervals and settings are transferred into the timer through an infrared programmer, providing complete isolation from switching current.
Intervals and input settings are defined using Phenix Programmer Software which is available online for FREE. Timer settings are then read from the computer screen using an infrared remote programmer, model 9211, or through the USB interface, model 9245. The interval program is then transmitted from the remote to the infrared input on the timer. |
|
|
| Operating Voltage |
|
| Output |
|
| Time |
|
| Features |
|
|
|
|
|
|
| 1 |
$
|
60.00 |
| 5 |
$
|
52.00 |
| 10 |
$
|
49.00 |
| 50 |
$
|
43.00 |
| 100 |
$
|
40.00 |
|
|
|
